Efficient and adaptable metallic double diaphragm pumps!
This solid and very compact double membrane pump is available in a wide variety of materials such as aluminium, stainless steel or special materials (e.g. Hastelloy®). This series has proven itself especially in applications for hygienic product transfer of viscous products such as cosmetics, dairy products or mayonnaise.
The pumps of the Slimline series can be equipped with ball lifters that allow complete residual emptying.
Features of the Slimline series
- Very compact as well as hygienic design
- Self-priming (suction height up to 3.6m dry)
Conformity: FDA, UPS Class VI and (EC) 1935/2004 (EU) 2023/2006 - Surface finish from 0.38Ra to 0.8Ra on wetted surfaces
- Membrane rupture protection (barrier chamber system) for the protection of people and the environment optionally available
- "ONE-NUT" technology for easy and quick maintenance
- ATEX directive compliant up to gas group IIC
- Optional high-temperature membranes allow a maximum working temperature of max. 135°C
- Connection sizes from DN15 to DN80 and choice of a range of screw, flange or hygienic connections
- No lubrication required
Adavantages
- Maintaining safety levels in hazardous environments and operations.
- Reduce downtime and maintenance costs.
- Increase in productivity.
