3-piece Ball Valve DG1 Orbital weld ends
Series DG1 Type8 (ORBITAL weld ends)
Technical data
Ball valve for welding in ORBITAL welding process, 3-piece body, pressure class depending on the nominal size up to PN 125, floating ball, vacuum-tight.
Sizes DN 8 - DN 100
Bore Full bore
Special features For the application with ultra-clean media
Pipe dimensions Can be adapted to customer specification
Mounting flange DIN EN ISO 5211
Test DIN EN 12266 P10 P11 P12, leakage rate A
Industries and applications
Chip industry
Chemical industry
Process plants
Food industry (->Application in deep-frying systems)
Ultra-clean media
Available materials
| Body | 1.4408, 1.4529 |
| Ball | 1.4408, 1.4529, Ceramic |
| Stem | 1.4542 (17-4PH), 1.4529 |
| End connectors |
1.4408, 1.4409, 1.4529, steel 1.0619 (GS-C25) |
| Seat and body rings |
PTFE, PFTE/glass, PTFE/carbon, PEEK, UHMWPE, POM, PVDF |
* If you have any other material requirements, please contact us!
